Example of a Simple Bobcat A300 Installation
1: Monitor was easily mounted in overhead screen.
2: Power cable was run behind top console where there are many unused power wires which are run from the main switch. By using a wire connector, we were able to tap into the main power and ground with little effort.
3: Main camera cable was run down the right side and under the cab, across the right side of the frame (away from the motor and controls) and out to the hinge side of the door.
4: Mounting holes that were already on place were enlarged for the camera cable to be inserted through.
5: The camera was Mounted and the excess cable tucked inside the motor compartment and tye wrapped out of the way.
All of this was accomplished in less than 1 hour!
|
